150W thin film flexible solar panel module ,rollable solar panels for car
High efficiency bendable solar module adopts the highest efficiency cell in the world from USA, with efficiency up to 20% or highter,which enable 25-30% higher power generation than the conventional PV modules at the same size.
By adopting the back contact technique,the cell can be coated with the flexible materials and finally forms the high efficiency flexible solar panel.this kind of solar panel can be widely used in the field of Electric Golf Car,Patrol Car,Travel Tourism Car,Yacht,Roof Power generation,Backpack,Tent and so on.
Above 135W to 300W also can do.
The ocean series of modules are high quality mono-crystalline silicon cell modules with the versatility of being both lightweight and semi flexible. The modules are particularly suitable for yachts, caravans,
and mobile homes as they can be mounted on slightly curved surfaces, are extremely robust and are practically theft proof when bonded down.
Product Description
Model | Solar-90W | Solar-150W |
Pmax(wp) | 90 | 150 |
Vmp(V) | 20.6 | 37.1 |
Imp(A) | 4.37 | 4.37 |
Voc(v) | 25.6 | 46.1 |
Isc | 4.89 | 4.89 |
N/W(kg) | 1 | 2 |
Dimension(mm) | 960*640*1 | 1665*646*1 |
Number of cells | 40(20*2) | 72(36*2) |
Power Tolerance | 3% | 3% |
Encapsulation | ETFE lamination+EVA+Cellls+EVA+TPT | |
Junction box | Ip67 rated9(built in bypass diode) | |
Solar cells advantage | Each cell built in bypass diodes | |
Color | Black |
